Mac mini Technical Specifications
Silver
Apple M6
chip
- 12‑core CPU with 2 super cores, 4 performance cores and 6 efficiency cores
- 12-core GPU
- Neural Accelerators
- Hardware-accelerated ray tracing
- Dual 16‑core Neural Engine
- 153GB/s memory bandwidth
Media Engine
- Hardware-accelerated H.264, HEVC, ProRes and ProRes RAW
- Video decode engine
- Video encode engine
- ProRes encode and decode engine
- AV1 decode
Not configurable
Apple M6
chip
- 12‑core CPU with 2 super cores, 4 performance cores and 6 efficiency cores
- 12‑core GPU
- Neural Accelerators
- Hardware-accelerated ray tracing
- Dual 16‑core Neural Engine
- 153GB/s memory bandwidth
Media Engine
- Hardware-accelerated H.264, HEVC, ProRes and ProRes RAW
- Video decode engine
- Video encode engine
- ProRes encode and decode engine
- AV1 decode
Not configurable
Apple M6
chip
- 12‑core CPU with 2 super cores, 4 performance cores and 6 efficiency cores
- 12‑core GPU
- Neural Accelerators
- Hardware-accelerated ray tracing
- Dual 16‑core Neural Engine
- 170GB/s memory bandwidth
Media Engine
- Hardware-accelerated H.264, HEVC, ProRes and ProRes RAW
- Video decode engine
- Video encode engine
- ProRes encode and decode engine
- AV1 decode
Not configurable
Apple M5
Pro chip
- 15‑core CPU with 5 super cores and 10 performance cores
- 16‑core GPU
- Neural Accelerators
- Hardware-accelerated ray tracing
- 16‑core Neural Engine
- 307GB/s memory bandwidth
Media Engine
- Hardware-accelerated H.264, HEVC, ProRes and ProRes RAW
- Video decode engine
- Video encode engine
- ProRes encode and decode engine
- AV1 decode
Configurable to:
- M5 Pro with 18‑core CPU and 20‑core GPU
16GB
- 16GB unified memory
Configurable to:
- 24GB or 32GB (170GB/s memory bandwidth)
16GB
- 16GB unified memory
Configurable to:
- 24GB or 32GB (170GB/s memory bandwidth)
24GB
- 24GB unified memory
Configurable to:
- 32GB
24GB
- 24GB unified memory
Configurable to:
- 48GB or 64GB
256GB
- 256GB SSD
Configurable to:
- 512GB, 1TB or 2TB
512GB
- 512GB SSD
Configurable to:
- 1TB or 2TB
512GB
- 512GB SSD
Configurable to:
- 1TB or 2TB
512GB
- 512GB SSD
Configurable to:
- 1TB, 2TB, 4TB or 8TB
M6
Supports up to three external displays using Thunderbolt and HDMI ports:
- Three displays: Two displays up to a native resolution of 6K at 60Hz or 4K at 165Hz, plus a third display up to 5K at 60Hz over Thunderbolt or 4K at 60Hz over HDMI
- Up to two displays: One display up to a native resolution of 8K at 60Hz or 5K at 120Hz or 4K at 240Hz, plus a second display up to 5K at 60Hz over Thunderbolt or 4K at 60Hz over HDMI
- Supports up to two external displays over a single Thunderbolt port
- Thunderbolt 4 (USB‑C) ports support native DisplayPort 1.4 speeds
- Supports variable refresh rate (VRR), HDR and multi‑channel audio
M5 Pro
Supports up to three external displays over any combination of Thunderbolt and HDMI ports:
- Three displays up to a native resolution of 6K at 60Hz or 4K at 165Hz
- Up to two displays: One display up to a native resolution of 8K at 60Hz or 5K at 120Hz or 4K at 240Hz, plus a second display up to 5K at 120Hz or 4K at 200Hz
- Supports up to three external displays over a single Thunderbolt port
- Thunderbolt 5 (USB‑C) ports support native DisplayPort 2.1 speeds
- Supports variable refresh rate (VRR), HDR and multi‑channel audio
- Supported formats include HEVC, H.264, AV1 and ProRes
- HDR with Dolby Vision, HDR10+/HDR10 and HLG
- Supported formats include AAC, MP3, Apple Lossless, FLAC, Dolby Digital, Dolby Digital Plus and Dolby Atmos
- Built-in speaker
- 3.5mm headphone jack with advanced support for high-impedance headphones
- HDMI port supports multi-channel audio output
On front:
- Two USB-C ports with support for USB 3 (up to 10Gb/s)
- 3.5mm headphone jack
On back (M6):
- 2.5Gb Ethernet port
(configurable to 10Gb Ethernet) - HDMI port
Three Thunderbolt 4 (USB-C) ports with support for:
- Thunderbolt 4 (up to 40Gb/s)
- USB 4 (up to 40Gb/s)
- DisplayPort
On back (M5 Pro):
- 2.5Gb Ethernet port
(configurable to 10Gb Ethernet) - HDMI port
Three Thunderbolt 5 (USB-C) ports with support for:
- Thunderbolt 5 (up to 120Gb/s)
- USB 4 (up to 40Gb/s)
- DisplayPort
Wireless
- Apple N1 wireless networking chip
- Wi‑Fi 7 (802.11be)2
- Bluetooth 6
- Thread networking technology
Ethernet
- 100/1000/2500BASE‑T Multi‑Gigabit Ethernet (RJ‑45 connector)
- Configurable to 10Gb Ethernet (Nbase-T Ethernet with support for 1Gb, 2.5Gb, 5Gb and 10Gb Ethernet using RJ-45 connector)
- Line voltage: 100–240V AC
- Frequency: 50Hz to 60Hz, single phase
- Maximum continuous power: 155W
- Operating temperature: 10° to 35° C (50° to 95° F)
- Storage temperature: –40° to 47° C (–40° to 116° F)
- Relative humidity: 5% to 90% non-condensing
- Operating altitude: tested up to 5,000 metres (16,400 feet)
- Typical acoustical performance: sound pressure level (operator position): 5 dBA at idle4
In Ireland, consumers are entitled to a free-of-charge repair or replacement, by the seller, of goods that do not conform with the contract of sale. Under Irish law, consumers have up to six years from the date of delivery to exercise their rights; however, various factors may impact your eligibility to receive these remedies. For more details, click here.
Your Mac mini also comes with 90 days of complimentary technical support and a one-year limited warranty from Apple. To learn more about how Apple will service your Mac mini, click here.
Purchase AppleCare+ to get up to three years of expert technical support and hardware coverage, including unlimited repairs for accidental damage from handling, each subject to an excess fee. For more information, click here.
- Mac mini
- Power lead (1.8m)
macOS
macOS is the most advanced desktop operating system in the world. Siri AI is a powerful and capable assistant with personal context understanding, broad world knowledge and onscreen awareness. Express yourself through photos and images, save time with Safari, and get more done with Apple Intelligence seamlessly integrated into your everyday apps and experiences. And window tiling, Sidecar and more help you stay productive.
The next generation of Apple Intelligence is centred around you, integrated into your apps and built with privacy at its core. Apple Intelligence powers Siri AI — an entirely new version of Siri that’s more personal, conversational and powerful — along with helpful features across apps.
Accessibility features help people with disabilities get the most out of their new Mac mini. With built-in support for vision, hearing, mobility and learning, you can create and do amazing things.
Features include:
- VoiceOver
- Zoom
- Motion, display and text settings
- Accessibility Reader
- Voice Control
- Switch Control
- Closed Captions
- Live Captions
- Personal Voice and Live Speech
Configure your Mac mini with these options at apple.com:
Model 1
- Not configurable
- 24GB or 32GB unified memory
- 512GB, 1TB or 2TB SSD
- 10Gb Ethernet
Model 2
- Not configurable
- 24GB or 32GB unified memory
- 1TB or 2TB SSD
- 10Gb Ethernet
Model 3
- Not configurable
- 32GB unified memory
- 1TB or 2TB SSD
- 10Gb Ethernet
Model 4
- M5 Pro with 18‑core CPU, 20‑core GPU and 16‑core Neural Engine
- 48GB or 64GB unified memory
- 1TB, 2TB, 4TB or 8TB SSD
- 10Gb Ethernet
